MIFARE Classic® 1K Contactless Smart Card

The MIFARE Classic® 1K contactless smart card is based on NXP MF1 IC S50, which is connected to a coil with a few turns and then embedded into plastic to form the passive contactless smart card. The communication layer (MIFARE RF Interface) complies with part 2 and 3 of the ISO/IEC14443A standard. It is contactless transmission of data and energy and no battery is needed.
MIFARE Classic® 1K is fundamentally used for storing memories, while a simple security mechanism divides the memories into segments. Therefore, it is ideal for high volume transactions in all different applications, such as transport ticketing, time attendance solutions, car parking, road-tolling etc. It is mainly used in closed systems as fixed value tickets (e.g. weekly/monthly travel passes).

    Mifare 1K Card
  • Frequency : 13.56MHz
  • Protocol : ISO14443A
  • Unique ID : 32 bits
  • EEPROM Size : 1024 Bytes
  • Material : PVC
  • Temperature : -20°C ~ +50°C
  • Dimension : 85.6 × 54 × 0.86 ( mm )
  • Datasheet :   M001052
  •   Quotation
Quantity EXW Price USD
Blank Cards Printed
4C + 4C
UID/Serial Number Printed Electronic
Personalization
Jet Thermal Laser
1 - 999 $0.65 - - - - -
1,000 - 4,999 $0.59 + $0.03 + $0.01 + $0.02 + $0.05 + $0.05
5,000 - 9,999 $0.55 + $0.01
10,000 - 49,999 $0.51 + $0.01
50,000 - 99,999 $0.48 + $0.01
>100,000 $0.46 + $0.01
